Power Transformer

• Up to 240MVA

• Generator Step-up Transformers (Renewable and Nuclear)

• Transmission Network Transformers

• Distribution Small and Medium Transformers

• Transformers other than standard specifications are also manufactured according to customer request.

DOWNLOAD

Introduce
Company Advantages
Products Advantages
Parameters
Applications

What is a power transformer?

Power transformers are electrical instruments used in transmitting electrical power from one circuit to another without changing the frequency.

They operate by the principle ofelectromagnetic induction. They are used in transmitting electrical power between generators and distribution primary circuits.

A power transformer is a mere classification of transformers with a voltage range varying between 3 kv-400 kV and a ratin above 200 MVA. The voltaeratings of power transformers avalilable in the market indlude 400 kv, 200 y, 110 ky,66 ky, and 33 kv. The other types of transformers include distribution (230V-11kV) and instrument transformers.

Power transformers are essentialin minimizing substantial energy losses, due to joule's efect,in the transmission of large amounts of electrica power overong distances by converting it into high-voltape current then stepping it down to a safer low-voltape current. They are commonly found in power plants,industrial plants, and electric utility companies.

Company Advantages

JiangsuYawei transtormers have been successtuly exported to severa countries incuding the United Stotes, Canada, Panama, Venezuela, Uzbekistan,Australia,and Bulgaria.

We have sufficient production capacity to ensure that goods can be delivered on time. We have professional after-sales teams around the world, this ensures prompt trouble shooting and resolution of any issues you may encounter.
Whether you are a utlity company, transformer distributor, or builder, you can purchase JiangsuYawei's power transformer with confidence,knowing that you are investing in a reliable and reputabe product.Experience the efficiency and reliablity of JiangsuYawei Transtormer tailored to meet your specific needs.

JSYW Power Transformer Product

The JSYW Power Transformer product is a premium-grade power transformer that provides reliable service to customers. The transformer is manufactured using high-quality raw material procured from the most reputed vendors in the industry.

Several features like easy installation and low maintenance cost ensure optimum performance under unfavorable weather conditions for long durations.

Parameters

Rated Capacity(kVA)	Voltage combined		Vector-group	No-load Loss (kw)	Load loss (kw)75℃	No-load current (％)	Short-circuit Impendance
Rated Capacity(kVA)	HV(kV)	LV(kV)	Vector-group	No-load Loss (kw)	Load loss (kw)75℃	No-load current (％)	Short-circuit Impendance
6300	110±8×1.25％	6.36.610.511	YNd11	10.0	36	0.80	10.5
8000				12.0	45	0.80
10000				14.2	53	0.74
12500				16.8	63	0.74
16000				20.2	77	0.69
20000				24.0	93	0.69
25000				28.4	110	0.64
31500				33.8	133	0.64
40000				40.4	156	0.58
50000				47.8	194	0.58
63000				56.8	234	0.52

Applications

Power transformers used in electric power generation and distribution Used for reducing power losses during electric power transmission They are preferred in cases where the load is required to run at full capacity 24×7. It is used in high voltage step-up and step-down.
